400ML Compact Battery Materials Grinding Ball Mill Machine With Optional Ball

Name: 400ML Compact Battery Materials Grinding Ball Mill Machine With Optional Ball
Brand: Xiamen Acey New Energy Technology Co., Ltd
SKU: ACEY-VPM-400ML
Price: 1,480.00 USD
Availability: InStock

Brand Name:	ACEY
Model Number:	ACEY-VPM-400ML
MOQ:	1 Set
Price:	USD1450~1511/Set
Payment Terms:	T/T,PayPal,L/C,Western Union,MoneyGram
Supply Ability:	200 Sets/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Compatible Grinding Jars:

100ml * 4

Max Feeding Capacity:

1/3 Capacity Of The Grinding Jar

Roll Placement:

Vertical Placement

Rotational Speed Of Grinding Jar:

1100rpm

Dimensions:

502mm*300mm*298mm

Equipment Weight:

30KG /40KG

Place Of Origin:

China

Warranty:

1 Year Warranty With Lifetime Support

Certification:

Packaging Details:

Plywood Case

After-sales Service:

24/7 Technical Support

Packaging Details:

Plywood Case

Highlight:

400ml compact ball mill machine

battery materials grinding ball mill

cylindrical cell assembly ball mill

Product Description

400ML Compact Battery Materials Grinding Ball Mill Machine With Optional Ball

Product Overview

The ACEY-VPM-400ML Planetary Ball Mill Machine performs dry grinding, suspension grinding, or operations in inert gas environments. Beyond comminution, this versatile equipment handles mixing and homogenizing of emulsions and pastes, as well as mechanical alloying and activation in material research. With its compact design, comprehensive functionality, high efficiency, and low noise operation, it serves as an ideal solution for research sample preparation in institutes, universities, and enterprise laboratories—capable of processing four samples simultaneously. When equipped with vacuum ball milling tanks, it can grind samples under vacuum conditions. Applications span Geology, Mining, Metallurgy, Electronics, Construction Materials, Ceramics, Chemical Engineering, Light Industry Medicine, and Environmental Protection.

Key Features

Elegant design for user-friendly operation

Suitable for both wet and dry grinding applications

Automatic and programmable control with intuitive LED display

Multiple selectable grinding modes for various process needs

High uniformity and excellent repeatability of results

High rotational speed, efficient performance, and fine particle size

Capable of processing four samples of varying sizes and materials in a single run

Programmable interval and pause times for flexible operation

Stepless speed adjustment with reversing function

Wide selection of materials available for grinding tools

Gear-drive mechanism eliminates issues commonly associated with belt drives

Low center of gravity, high rigidity, compact structure, low noise, and reliable, safe operation—minimal pollution and wear

Built-in fan cooling system enables extended grinding durations

Technical Specifications

Working Principle	Impact and friction force
Compatible Grinding Jars	100ml * 4
Max Feeding Capacity	1/3 capacity of the grinding jar
Operation Mode	2 or 4 grinding jars working simultaneously
Feeding Granularity	Soil materials < 10mm, other materials < 3mm
Discharging Granularity	Down to 0.1μm
Sample Type	Hard, medium-hard, soft, fibrous, brittle, moist
Rotational Speed of Grinding Jar	1100rpm
Rotational Speed Ratio	1 : -2
Drive Mode	Gear drive and belt drive
Speed Control	Stepless speed regulation
Electrical Details	AC110/220V, 50/60Hz, 0.25KW
Max Continuous Grinding Time	72 hours (full-load)
Weight (Net / Gross)	30KG / 40KG
Dimension (LWH)	502mm * 300mm * 298mm
Size of Planetary Disk	Dia190mm * T6mm

Product Image
