2L Low-noise Vertical Planetary Ball Milling Machine For Laboratory

Name: 2L Low-noise Vertical Planetary Ball Milling Machine For Laboratory
Brand: Xiamen Acey New Energy Technology Co., Ltd
SKU: ACEY-VHBM-2L
Price: 2,399.00 USD
Availability: InStock

Brand Name:	ACEY
Model Number:	ACEY-VHBM-2L
MOQ:	1 Set
Price:	USD 2350~2449/Set
Payment Terms:	T/T,PayPal,L/C,Western Union,MoneyGram
Supply Ability:	200 Sets/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Compatible Grinding Jars:

(250ml~1500ml) * 4

Max Feeding Capacity:

1/3 Capacity Of The Grinding Jar

Roll Placement:

Vertical Placement

Sample Type:

Hard, Medium-hard, Soft, Fibrous, Brittle, Moist

Dimensions:

720*480*630mm

Equipment Weight:

140KG

Place Of Origin:

China

Warranty:

1 Year Warranty With Lifetime Support

Certification:

Packaging Details:

Plywood Case

After-sales Service:

24/7 Technical Support

Packaging Details:

Plywood Case

Highlight:

2L laboratory ball milling machine

low-noise planetary ball mill

vertical ball mill for lab

Product Description

2L Low-noise Vertical Planetary Ball Milling Machine For Laboratory

The ACEY-VHBM-2L planetary ball mill supports dry grinding, wet grinding in suspension, and operation under inert gas atmospheres. In addition to size reduction, it is suitable for mixing and homogenizing emulsions and pastes, as well as for mechanical alloying and material activation in research applications. Compact in design yet fully functional, the instrument delivers high efficiency with low noise levels. It offers an ideal solution for obtaining research samples in institutes, universities, and industrial laboratories, with the capability to process up to four samples simultaneously in a single run. When equipped with vacuum-compatible milling jars, samples can also be ground under vacuum conditions. The system is widely applied across various fields including geology, mining, metallurgy, electronics, construction materials, ceramics, chemical engineering, light industry, pharmaceuticals, and environmental protection.

Key Features

Multiple grinding modes to choose from
High uniformity and excellent repeatability
Fast rotational speed, high efficiency and fine granularity
Four samples with different sizes and materials in one experiment
Programmable interval and pause times
Stepless speed regulation with reversing function
Large range of materials available for grinding tools
Gear-drive offers effective solution to belt driving problems
Low center of gravity, good rigidity, compact structure, low noise
Safe and reliable operation with no pollution and minimal wear
Cooling of grinding chamber with built-in fan for extended operation

Technical Specifications

Working Principle	Impact and friction force
Compatible Grinding Jars	(250ml~1500ml) * 4
Max Feeding Capacity	1/3 capacity of the grinding jar
Operation Mode	2 or 4 grinding jars working simultaneously
Feeding Granularity*	Soil materials < 10mm, others materials < 3mm
Discharging Granularity	Down to 0.1μm
Sample Type	Hard, medium-hard, soft, fibrous, brittle, moist
Rotational Speed of Grinding Jar	800rpm
Rotational Speed Ratio	1:2
Drive Mode	Gear drive and belt drive
Speed Control	Stepless speed regulation
Electrical Details	110V/220VAC, 50/60Hz, single phase, 0.75KW
Max Continuous Grinding Time	72 hours (full-load)
Weight	140KG
Dimension (LWH)	720480630mm
Noise Level	< 70dB
