| Brand Name: | ACEY |
| Model Number: | ACEY-HFC250 |
| MOQ: | 1 Set |
| Price: | USD 2380~2480/Set |
| Payment Terms: | T/T,PayPal,L/C,Western Union,MoneyGram |
| Supply Ability: | 200 Sets/Month |
The ACEY-HFC250 film coating machine is widely used in research involving various high-temperature coating films, including ceramic films, crystalline layers, battery material coatings, and specialized nano-films. The equipment is designed to support future technological advancements in high-temperature film formation.
| Heating drying system | Room temperature～150℃, digital display temperature controller, accuracy ±1℃ |
| Coating method | Flat coating, standard film maker (can be enlarged), optional scraper, wire rod and other gauges |
| Coating width | Adjustable from 6.4-100mm, coating stroke approximately 250mm, stroke steplessly set and adjusted via touch screen |
| Coating drive | Motor drive, coating speed steplessly set and adjusted via touch screen |
| Coating speed | 0～120mm/sec (e.g., lithium iron phosphate slurry) |
| Scraper adjustable range | 0～6mm adjustable |
| Vacuum plate size | L365mm×W200mm×H32mm |
| Vacuum plate | Aluminum plate with vacuum |
| Accuracy | ±3μm, optional display 1μm dial indicator |
| Power supply | 220V/50Hz |
| Weight | 50KG |
| Dimensions | L505mm×W355mm×H325mm |
| Packing details | Includes 1 built-in oil-free vacuum pump |
